TTBOT XZ25 Motor | Robot Servo Motor for Robotics Development

  • TTBOT robot servo motor for robot joints, actuator assemblies, automation hardware, and robotics development.
  • Suitable for engineering teams building research robots, education platforms, prototypes, and motion-control systems.
  • Designed for practical integration in robot actuator, compact mechanism, and embedded control applications.
  • Useful for robotics labs, automation engineers, and hardware developers selecting motor components for robot platforms.
$640
Version

Warranty
  • 1-year limited warranty for the main unit.
  • 6-month limited warranty for the battery.
  • For service support, please contact customer care with proof of purchase.

Shipping

• Free shipping on qualifying orders. Eligibility and exact rates are calculated at checkout.
• Typical delivery 9 – 15 business days.
• Need it faster or shipping something large? Contact us for expedited options and a freight quote.

Developer Support

TTBOT XZ25 Motor dimension drawing for installation reference.pdf ▶ TTBOT XZ25 Motor CAD model for mechanical integration.stp ▶
TTBOT XZ25 Motor | Robot Servo Motor for Robotics Development detail image 1
TTBOT XZ25 Motor | Robot Servo Motor for Robotics Development detail image 2
TTBOT XZ25 Motor | Robot Servo Motor for Robotics Development detail image 3
TTBOT XZ25 Motor | Robot Servo Motor for Robotics Development detail image 4
TTBOT XZ25 Motor | Robot Servo Motor for Robotics Development detail image 5
▤ PARAMETER ⌃
Module Model
XZ25
Supply Voltage
48VDC
Rated Torque
35N.m
Starting Torque
105N.m
Peak Torque
110N.m
Rated Speed
60rpm
Peak Speed
120rpm
Communication
CAN
Encoder
15-bit single-turn absolute
Protection Grade
IP6X
Operating Noise
≤65dBA(@1m 60rpm)
Weight
4.2kg
Operating Temperature
0~40℃
Motor Rated Current
8.5Arms
Motor Peak Current
15.4Arms
Motor Rated Speed
3000rpm
Motor Rated Torque
1.27N.m
Back EMF Constant
4.97Vrms/Krpm
Torque Coefficient
0.073N.m/Arms
Motor Rotor Inertia
0.51×10^-4kg.m^2
Insulation Class
B
Reduction Ratio
1:51
Backlash
≤1arcmin
Number of Teeth
40
Module
2
Pressure Angle
20°
Tip Diameter
83.96 ~0.05 mm
Root Diameter
75mm
Span Teeth Number
5
Common Normal Length
27.69 ~0.05 mm
Gear Material
40Cr
