AGILE ROBOTS

AGILE ROBOTS Diana7 7-DOF Robotic Arm | Collaborative Robot Arm for Research

  • 7-DOF robotic arm platform for robotics research and automation development.
  • Collaborative robot arm design for lab, education, and engineering workflows.
  • Suitable for robot manipulation, embodied AI research, and advanced control experiments.
  • Includes source product documentation and downloadable support resources.
  • Built for developers and research teams working on robotic arm applications.
$61,900
Title

Warranty
  • 1-year limited warranty for the main unit.
  • 6-month limited warranty for the battery.
  • For service support, please contact customer care with proof of purchase.

Shipping

• Free shipping on qualifying orders. Eligibility and exact rates are calculated at checkout.
• Typical delivery 9 – 15 business days.
• Need it faster or shipping something large? Contact us for expedited options and a freight quote.

Developer Support

AGILE ROBOTS Diana7 dimensional drawing PDF with robot outline and mounting dimensions ▶ AGILE ROBOTS Diana7 technical data sheet with payload, reach, accuracy, safety, and controller specifications ▶

AGILE ROBOTS Diana7 Robotic Arm

The AGILE ROBOTS Diana7 is a 7-DOF robotic arm platform for robotics research, automation development, and collaborative robot applications. It is suitable for labs and engineering teams building robot manipulation workflows.

Features

  • **7-DOF robotic arm:** Designed for flexible robotic manipulation research.
  • **Collaborative robotics platform:** Suitable for robot development, lab automation, and education.
  • **Research-focused use cases:** Supports embodied AI, manipulation, and automation workflows.
  • **Developer resources:** Local PDF resources are prepared for Shopify resource entries.
AGILE ROBOTS Diana7 robotic arm detail image 1
AGILE ROBOTS Diana7 robotic arm detail image 2
AGILE ROBOTS Diana7 robotic arm detail image 3
▤ PARAMETER ⌃
Load
7 kg
Arm Span
923 mm
Degrees of Freedom
7
Repeat Positioning Accuracy
±0.05mm
End Tool Connector
Complies with ISO 9409-1-50-4-M6
Working Temperature
90% RH (non-condensing)
Joint 1 Movement Range
-179° ~ 179°
Joint 2 Movement Range
-90° ~ 90°
Joint 3 Movement Range
-179° ~ 179°
Joint 4 Movement Range
0° ~ 175°
Joint 5 Movement Range
-179° ~ 179°
Joint 6 Movement Range
-179° ~ 179°
Joint 7 Movement Range
-179° ~ 179°
Body Weight
28 kg
Base Diameter
Φ 190 mm
TCP Max Linear Speed
2.4m/s
Programming Method
Graphical programming environment, script programming, API programming
Force Control Relative Accuracy
0.5N
Working Temperature
0~50°C
Joint 1 Max Speed
170°/s
Joint 2 Max Speed
170°/s
Joint 3 Max Speed
170°/s
Joint 4 Max Speed
170°/s
Joint 5 Max Speed
210°/s
Joint 6 Max Speed
210°/s
Joint 7 Max Speed
210°/s
Controller-Weight
16 kg
Controller-Working Temperature
0 ~ 50 °C
Controller-Working Humidity
90% RH (non-condensing)
Controller-Power Supply
AC 110 - 240 V, 50 / 60 Hz
Controller-Communication Method
Modbus-TCP communication, TCP/IP communication, RS232 communication
Controller-Cable Length
3.0 m
Control frequency
1000 Hz
Controller-I/O Power
24 V / 2.5 A
Controller-Dimensions
483 mm × 377 mm × 192 mm
Controller-I/O Ports
16 DI / 16 DO 2 AI / 2 AO (standard), 32 DI / 32 DO 2 AI / 2 AO (optional), 48 DI / 48 DO 2 AI / 2 AO (optional)
Teach Pendant-Resolution
1280 x 800
Teach Pendant-Screen Type
TFT color LCD
Teach Pendant-Buttons
Emergency stop switch, mode switching key switch, three-position enabling button, configurable buttons
Screen size
12.1'
Cable length
8.0 m
Interface
USB 2.0
