MagicLab

MagicLab MagicBot Z1 Robot

  • MagicLab humanoid robot platform for embodied AI, robotics research, and education lab development.
  • Suitable for developers evaluating robot mobility, autonomy, interaction, and applied robotics workflows.
  • Designed for universities, research teams, integrators, and labs building next-generation robot applications.
  • Useful for prototyping, demonstrations, automation experiments, and AI robotics development.
$52,800
Version

Warranty
  • 1-year limited warranty for the main unit.
  • 6-month limited warranty for the battery.
  • For service support, please contact customer care with proof of purchase.

Shipping

• Free shipping on qualifying orders. Eligibility and exact rates are calculated at checkout.
• Typical delivery 9 – 15 business days.
• Need it faster or shipping something large? Contact us for expedited options and a freight quote.

Developer Support

MagicLab MagicBot Z1 Robot software documentation for development support.zip ▶
MagicLab MagicBot Z1 Robot | Humanoid Robot Platform for Robotics Research detail image 1
MagicLab MagicBot Z1 Robot | Humanoid Robot Platform for Robotics Research detail image 2
▤ PARAMETER ⌃
Specification
Z1 Z1 Development Version
Height, Width, Thickness (Standing)
1369 × 422 × 200 mm 1369 × 422 × 200 mm
Height, Width, Thickness (Folded)
730 × 422 × 595 mm 750 × 422 × 595 mm
Weight with Battery
Approximately 40kg Approximately 40kg+
Total Degrees of Freedom (Number of Joints)
24 24 - 50
Single Leg Degree of Freedom
6 6
Head Degree of Freedom
1 1
Waist Degree of Freedom
1 1
Single Arm Degrees of Freedom
5 5 + (2 additional wrist degrees of freedom can be optionally selected)
Degrees of Freedom of Dexterous Hand
/ Optional 11-DOF tactile dexterous hand
Joint Output Bearing
Industrial-grade high-rigidity roller bearing (capable of withstanding 8.7kN impact force) Industrial-grade high-rigidity roller bearing (capable of withstanding 8.7kN impact force)
Joint Motor
Low inertia, high-speed, high-overload permanent magnet synchronous motor (control frequency 25kHz, high burst power, better heat dissipation) Low inertia, high-speed, high-overload permanent magnet synchronous motor (control frequency 25kHz, high burst power, better heat dissipation)
Maximum Knee Torque
100 N·m 130 N·m
Maximum Arm Load
2kg 3kg
Shank + Thigh Length
0.6 m 0.6 m
Arm Span
Approximately 0.5 m Approximately 0.5 m
Range of Motion of the Head Z-Axis Joint
±40° ±40°
Range of Motion of the Lumbar Z-Axis Joint
±160° ±160°
Range of Motion of the Knee Joint
0-152° 0-152°
Range of Motion of Hip Joint
P ±160°, R -30°+110°, Y ±160° P ±160°, R -30°+110°, Y ±160°
Joint Encoder
Dual Encoder Dual Encoder
Heat Dissipation System
Intelligent Air-cooled Heat Dissipation Intelligent Air-cooled Heat Dissipation
Power Supply Mode
15-cell battery 15-cell battery
Basic Computing Power
8-core high-performance CPU 8-core high-performance CPU
Perception Sensor
3D LiDAR + Depth Camera + Binocular Fisheye Camera + Head Tactile Sensor 3D LiDAR + Depth Camera + Binocular Fisheye Camera + Head Tactile Sensor
WiFi6, Bluetooth 5.2
Yes Yes
Microphone Array
Yes Yes
SW Speaker
Yes Yes
High Computing Power Module
None Optional
Smart Battery (Quick Release)
10000 mAh 10000 mAh
Charger
62V 5A 62V 5A
Handheld Remote Control
Yes Yes
Battery Life
Approximately 2h Approximately 2h
OTA Upgrade
Support Support
Secondary Development
None Yes
