Direct Drive Tech

Direct Drive Tech P1010A_111 Motor

  • Direct Drive Tech robot servo motor for robot joints, actuator builds, and motion-control development.
  • Suitable for robotics research, automation projects, education labs, and prototype hardware integration.
  • Designed for engineering teams working on compact direct-drive actuator and servo motor systems.
  • Supports robot hardware development where precise, integrated motion components are required.
$699
Version

Warranty
  • 1-year limited warranty for the main unit.
  • 6-month limited warranty for the battery.
  • For service support, please contact customer care with proof of purchase.

Shipping

• Free shipping on qualifying orders. Eligibility and exact rates are calculated at checkout.
• Typical delivery 9 – 15 business days.
• Need it faster or shipping something large? Contact us for expedited options and a freight quote.

Developer Support

Direct Drive Tech P1010A_111 Motor dimensional drawing for installation.pdf ▶

Direct Drive Tech P1010A_111 Motor

The Direct Drive Tech P1010A_111 Motor is a Direct Drive Tech motor for robotics development, actuator integration, robot joints, automation projects, and engineering research platforms.

Features

  • **Robotics integration:** Suitable for robot joints, compact actuators, and motion-control hardware.
  • **Engineering development:** Built for labs, robotics developers, automation engineers, and prototype teams.
  • **Direct-drive motor platform:** Useful for applications that require compact servo motor integration.
  • **Robot hardware builds:** Supports research, education, and automation systems requiring reliable actuator components.
Application Scenarios
Humanoid Robots Robotic Arms Exoskeletons Quadruped Robots AGV Vehicles ARU Robots
▤ PARAMETER ⌃
ltem Name
Direct Drive Tech P1010A_111 Motor
No-Load Speed (Current Loop)
≥170RPM
No-Load Current (Current Loop)
≤1.1A
Rated Speed
100±3 RPM
Rated Torque
25N·m
Rated Current (Bus)
6.6A±0.3A
Rated Voltage
48VDC
Voltage Range
36-60VDC (Default Under/Over-Voltage Thresholds)
Maximum Efficiency
≥79%
Overload Torque
≥90N·m
Overload Current (Bus)
≥35.0A
Torque Constant
2.5 Nm/A
Protection Rating (IP Rating)
IP2X
Noise Level
≤65 dB (Tested per GB/T 4214.1-2017 at 150 rpm)
Insulation Class
F
Number of Motor Pole Pairs
21
Number of Motor Slots
36
Motor Weight
1.4KG
Encoder Resolution (Bits)
15-bit (Rotor Position Detection) + 15-bit (Absolute Position Detection)
Motor Control Method
FOC
Phase Resistance
0.166Ω
Phase Inductance
0.175mH
Maximum Axial Load
300N
Maximum Radial Load
1500N
Bearing Basic Static Load Rating
8080N
Operating Ambient Temperature
-20-50℃
Rotor Inertia
5350g/cm^2
Reduction Ratio (Gear Ratio)
10:1
Backlash
<8arcmin
