Ti5 ROBOT

Ti5 ROBOT ARM Series 6-DOF Robotic Arm | ROS Robot Arm for Research & Automation

  • 6-DOF robotic arm series with 3 kg and 5 kg payload options.
  • 600 mm or 900 mm working radius with 0.05 mm repeatability.
  • Supports ROS, Python, and C++ for robotics research and automation development.
  • Aluminum alloy and resin construction with IP50 protection.
  • Optional Jetson Nano controller variant for robotics integration workflows.
$5,625
Version

Warranty
  • 1-year limited warranty for the main unit.
  • 6-month limited warranty for the battery.
  • For service support, please contact customer care with proof of purchase.

Shipping

• Free shipping on qualifying orders. Eligibility and exact rates are calculated at checkout.
• Typical delivery 9 – 15 business days.
• Need it faster or shipping something large? Contact us for expedited options and a freight quote.

Developer Support

Ti5 ROBOT ARM Series product manual with setup, specifications, and operating guidance ▶ Ti5 ROBOT ARM Series product overview with model information and application details ▶ Ti5 ROBOT ARM and EBLM Series robot user manual with operation and support information ▶

Ti5 ROBOT ARM Series 6-DOF Robotic Arm

The Ti5 ROBOT ARM Series is a 6-DOF robotic arm platform designed for robotics research, automation development, and engineering education. The series includes Ti5 Robot Arm-3 and Ti5 Robot Arm-5 models with different payload and reach configurations.

Both arm models support ROS, Python, and C++ interfaces, making the platform suitable for robotic arm research, lab automation, and software-driven robot development workflows.

Features

  • **Two payload options:** Ti5 Robot Arm-3 supports 3 kg payload, while Ti5 Robot Arm-5 supports 5 kg payload.
  • **Research-grade repeatability:** 0.05 mm repeatability for precise robotic arm motion experiments.
  • **ROS and Python support:** Built for robotics developers using ROS, Python, and C++ workflows.
  • **6-DOF motion platform:** Six-axis structure for manipulation, automation, and lab research tasks.
  • **Optional controller:** Jetson Nano controller variant supports edge robotics development.
Ti5 ROBOT ARM Series detail image 1
Ti5 ROBOT ARM Series detail image 2
Ti5 ROBOT ARM Series detail image 3
Ti5 ROBOT ARM Series detail image 4
▤ Technical Specifications ⌃
Parameter
Ti5 Robot Arm-5
Ti5 Robot Arm-3
Name / Model
Ti5 Robot Arm-5
Ti5 Robot Arm-3
Mass
18kg
12kg
Payload
5kg
3kg
Working Radius
900mm
600mm
Repeatability
0.05mm
0.05mm
DOF
6
6
Power
500W
300W
Interfaces & Openness
ROS, PYTHON, C++
ROS, PYTHON, C++
Power Supply Voltage Range
28～48V
28～48V
Joint Range of Motion
J1(±180°), J2(±90°), J3(±135°), J4(±180°), J5(±150°), J6(±180°)
J1(±180°), J2(±90°), J3(±135°), J4(±180°), J5(±150°), J6(±180°)
Max. Joint Speed
106°/s
106°/s
IP Rating
IP50
IP50
Material
Aluminum alloy, Resin
Aluminum alloy, Resin
Operating Temperature Range
0°C～50°C
0°C～50°C
Power Supply
DC 48V, 10A; DC 28V, 20A
DC 48V, 10A; DC 28V, 20A
USB
USB3.0*4
USB3.0*4
HDMI
HDMI2.0
HDMI2.0
I/O Interface
SPI/12C/GPI0/MART
SPI/12C/GPI0/LNRT
Standard Cable Length
1m
1m
