Unparalleled speed
The latest integrated joint enhances the joint speed to 223°/s, which is the highest in the industry.
This improvement allows for a wider range of application scenarios and boosts the production cycle time of common tasks like material handling by 25%. Consequently, it generates greater economic benefits.
Fast response
The EtherCAT bus is utilized by the joint servo, providing a vast bandwidth of hundreds of megabits and a joint response speed in the millisecond range. This remarkable combination greatly enhances the robot's movement speed and trajectory smoothness, enabling it to efficiently carry out a wide range of tasks.
Accurate positioning
Each robot is precisely calibrated with a laser calibration system, ensuring an absolute positioning accuracy of under 0.4 mm. This exceptional precision enables the robot to effortlessly tackle high-precision production tasks, thereby enhancing consistency and quality assurance in the production process.
20+ safety functions
Our robots utilize a stand-alone safety controller that is PLd Cat.3 rated, feature 20+ safety functions, and CRA has been certified with ISO 13849-1, ISO 10218-1, and ISO/TS 15066. With proper risk assessement, CRA can collaborate with humans without the need for additional fencing and ensure production safety.
Electromagnetic brake
In the event of an unexpected power outage, the robot swiftly engages its electromagnetic brake within 18 ms and ensures position retention within 1 mm, safeguarding against equipment or product damage.
Customizable safetystrategies
CRA provides virtual fencing and state-of-the-art non-contact skin protection, enabling users to devise safety measures tailored to their unique production settings. This ensures optimal safety at every stage of the production process.
Plenty of standard interfaces to reduce application costs
Our robots have an increased number of 24 DI and DO interfaces, supporting both PNP and NPN switching. They are also configured with more than 30 functions for robot control and status feedback, providing convenience and flexibility for seamless integration and control in the industrial automation field.
Additionally, our robots come equipped with standard communication methods like Modbus TCP/RTU, EtherNet/IP, PROFINET, and others. This guarantees effortless integration with popular PLCs, HMIs, and other devices, eliminating worries about communication protocol compatibility and enabling more efficient and streamlined device integration and configuration.
24 DI and DO interfaces
Modbus TCP/RTUEtherNet/IP
PNPandNPN: Switching supported
PROFINET: Multiple communication protocal supported
SafeSkinExclusive mass-producedsafe skin in the industry
Pre-collision sensing enhances safety and efficiency in the robots
15cm Pre-collision sensing
0.01s Fast monitoring
0.1s Fast response
1m/s Maximum human-robot interaction speed
DobotStudio Pro Software Platform
Blockly programming: The blocks offer an intuitive and user-friendly programming approach. By combining these blocks, you can create flexible programs for your robot effortlessly.
Script programming: Skilled developers can effectively design intricate programs and effortlessly manage advanced applications through the provision of adaptable LUA script programming.
Ecosystem Plugin: A wide range of ecosystem plugins is adapted to a variety of robot accessories, such as grippers, force sensors, 2D/3D vision, and etc. By directly utilizing the ready--to-use APIs from the plugins, users can efficiently accomplish application development in a short span of time.
Process package support: A range of application process packages is offered for welding, palletizing, CNC, and more. By adjusting parameters, programs can be easily created, resulting in faster robot applications. Additionally, tailored and specialized process packages can be developed for specific applications.
Powerful log function: The robot log enables you to access historical status, operation records, and parameter modification information at your convenience. This allows for swift problem identification and minimizes downtime.
Virtual controller: Users can leverage offline programming to execute, debug, and validate programs without being connected to the robot, resulting in expedited project implementation.
Multi-terminal operation: Different terminals(computer, tablet, teach pendant) is supported. And wired or wireless connection methods can be chosed according to different usage scenarios.
Teach Pendant
Featuring a lightweight and compact design, the DOBOT Teach Pendant seamlessly combines aesthetic and ergonomic features, resulting in a grip that is not only visually appealing but also comfortable to hold.
Its exceptional interaction design ensures safety, flexibility, and enhanced efficiency in robot debugging, delivering an excellent user experience.
ISOsafety certification
10.1-inch HD capacitive screen
3-position enable button
12physical jog button
VX500 smart camera, make cobot-vision application easier
Our robots are equipped with a 5-megapixel camera, an LED light source, and high-performance 2.5D algorithms, allowing them to integrate vision and communication functions seamlessly. They have exceptional precision in detecting changes in scene height and tilt, with an impressive spatial compensation accuracy of up to ±0.26mm. Moreover, their comprehensive error-proof detection algorithms enable the quick implementation of various vision applications, such as visual localization, measurement, inspection, and identification. The smart camera can be easily integrated with DOBOT CRA, providing a plug-and-play functionality. This eliminates the need for selecting, assembling, external wiring, and hardware and software debugging, making the process of building vision solutions hassle-free.
