Anybotics ANYmal

Industrial-grade and IP67
Purpose-built for intricate industrial plants. Ruggedized design, impact protection, dust and waterproof (IP67 rated) for all-weather operation.

Turn-key inspection suite
Fully integrated visual & thermal cameras, ultrasonic microphone, powerful LED spotlight and Lidar. Payload expandable to suit inspection requirements.

AI-based mobility and autonomy
ANYmal’s smart capabilities enable data collection in complex facilities autonomously and safely and the integration into existing operation systems.

Visual Camera
20× optical zoom for clear long-distance images and videos.

Pan-tilt Unit
High-range motion of the payload (+/- 90° vertical, +/- 165° horizontal) for quick and efficient readings.

Ultrasonic Microphone
Record acoustic measurements in audible and ultrasonic frequencies (0—384kHz).

Thermal Camera
Precise temperature readings in a range of -40–550°C without physical interaction.

Spotlight
Strong light of maximal 3790Im supports visual inspections in the dark.

Lidar Scanner
360° environment scanning for localization and reality capture.

Custom sensors for additional inspection requirements
ANYmal can carry an additional 10 kg payload and integrates with the listed solutions for gas sensing and acoustic imaging.

Detect gas leaks
ANYmal can be customized with an acoustic imager designed to inspect gas leakages and partial discharge events.

Detect gas presence
ANYmal can be customized with up to two gas concentration sensors designed to detect gas presence.

Mobile in complex facilities
AI-based mobility for navigating complex,
multi-floor plants made for humans.

Automatic docking
ANYmal takes smart action at low battery status and connects to a docking station to recharge.

Range extension
Expand ANYmal’s inspection reach by setting up multiple docking stations along the routes.

Hardware built for safety
ANYmal’s hardware design is safety-centric and compliant with international standards.
